Bio Electro Mechanical Aerobic Composting






Bio - Electro Mechanical aerobic Composting unit which order free out-put of compost. In short it is nothing but a neat & clean MSW processing facility in municipal word, hospitals, labrotaries, canteens, hotels, market yards and kind of public utility centers to produce the enrich compost.

• For Bio-logical processing Bio-column is used as a starter
• Unbalanced COD & BOD is taken care by using calcium and carbon adhesive i.e. (Wood Powder)
• For faster start of Bio-Composting Electric heating element is provided
• Start of Bio-Composting Electric heating element is provided
• Garden Shredder is added feature to take care of chunky garden waste such as branches, wood, clips etc.
M.O.C. : major portion of O.W.C. is in SS-304 material rest structure in M.S. Steel for Shredders in various type in different use is considered




OWC Machines Curing in Plastic Crate in Rack Storing

Model / Capacity
MVMP1-50Kg/day in 8hrs
MVMP1-100Kg / day in 8 hrs
MVMP1-250Kg / Day in 8hrs
Power 1.5 H.P. 3H.P. 7.5 H.P.
Overal Dimension To Suit To Suit To Suit
Approximate Gross Weight 100 Kg 150 Kg. 500Kg
Open Space for Curing 9M2 20M2 50M2
Space Required for Finished Storage 25M2 50M2 125M2
Man Power 1 2 3
Utility 25 Liter Water 50 Liter Water 100 Liter Water
Yield 20% 20% 20%
Bio-Culture (Bio-Calcum) 100gm 200 gm 500 gm
Composting & Slurry Period 07 days 07 days 07 Days
Moisture 30% 30% 30%

5/10 M Ton per Day Processing Through OWC (Windrow Cuing)
Shed Size 21 x 21 M
Shed Area 441 Sqm
Land Size As Per Availability
Land Area -do-

SR. NO.
EQUIPMENT& ACCESSORIES
SPECIFICATIONS
QTY HP
PRICE IN LACE
  OWC-PROCESSING UNIT 5-7.5 TPD
1 Composting Machine (Organic Waste Converter) Model: Continuous OWC, Capacity:1500 Kg Per Hr 1 3 7.5
2 Horizontal Belt (Segregation) 1m x 7m. Length 1 3 4
3 Conveyor Belt (In feed to shredder) 0.6 x 3.5 m. Length 1 3 4
4 Conveyor Belt (In Feed to OWC) 0.6 x5.0 m Length 1 3 4
5 Conveyor Belt (Out feed from OWC) 0.6 x5.0 m Length 1 3 4
6 Screw conveyor for absorbent Dia.150 mm 1 15 3
7 Shredder Capacity 2 Ton/hr 1 5 15
8 Squeezer
2 Ton/hr 1 -- 5
9 Leach ate Treatment plant Capacity 5000 lits 1 --
10 Standard reputed make skid steer loader or front end loader for windrow turning Engine 49 hp, shovel
capacity 0.36 cum
1 -- Direct Local
Purchase
11 Raw manure collection container Capacity-200 kg/Liter 2 -- 1
12 Vibro Screen Capacity-300 Kg/hr 1 3 3
  ELECTRICAL WORKS
13 Control panels With spares of standard make of Siemens or L& T /
Philips/ Bajaj or equivalent.
1 -- 1.5
14 Wiring and distributions Cabling, Distribution Box & Starters & Switches,
Lighting of standard make
1 -- 1
  COMMISSIONING CHARGES       2.5
      Total 38 55.5



O.W.C.

Chain Belt Conveyor






Chain Belt Conveyor
